• Specification - Input Signal: Mini Display Port 1.1a. - Output Video: HDMI/DVI/VGA. - Input: Mini Display Port Male 20pin. - Output: HDMI Female Type A 19pin. - Connector: DVI Female (24+1) VGA Female 15Pin. - Vertical Frequency Range: 50/60Hz.
• - Video Amplifier Bandwidth: 2.25Gbps/225MHz. - HDMI/DVI/VGA: 480i/480p,576p,720p,1080i/1080p. - External Power Supply: No external power needed. - Power consumption (Max): 700mW. - The Length of the cable: 28cm. - Package weight: 1.9 oz/54g.
• How to use The product is easily and conveniently use, with three output ports: DVI VGA HDMI and a Mini Display Port. And you can use one of them at a time as your demand, when you want to use the DVI output, you just need to connect the DVI devices using a DVI cable. And when you want to use the HDMI output, you just need to connect
• the HDMI devices using a HDMI cable. When you want to use the VGA output, you just need yo connect the VGA devices using a VGA cable. The Mini Display Port meed to connect Mac Book, Mac Book Pro, or Mac Book Air.

Overview

• Compatible Devices : Monitor, Projector, Television
• Specific Uses For Product : Amplifier
• Connector Type : Auxiliary, DVI, HDMI, VGA
• Color : black
• Item dimensions L x W x H : 3.54 x 1.77 x 0.79 inches
